Page 122 - Alfa International 2023 Catalog
P. 122
PARTS
HS1818
HS1879 HS1821
HS1823
HS6113
HS6101,
HS6102 HS1872
HS2150-232 HS6301
HS2145
HS1832
HS1881
HS6114, HS5901, HS3005, HS3010
HS6375 HS5902, HS3047
HS5903,
HS5904,
HS5905 HS1836
HS6110 Floor
Models Tabletop Models
1 1 1 1 5 5 6 6 6 8 8 8 8
HS6140, HS1824 0 0 0 1 0 0 0 2 2 0 2 5 7
HS6305 fits MoDels 2 4 7 2 0 0 0 5 5 0 5 0 5
A A A B A A A A A A A A A
/
Genuine HEAT SEAL Components HS6504 1 M i M i
0
AlfA heAt seAl hoBArt 7 n i n i
A
pArt # pArt # pArt # Description s
HS1818 1818001 00-132654-00006 Circuit Control Board x x x x x x x x x x x x x
HS1821 1821034 FE-016-40 1 Amp MDA Slo-Blo* Fuse (Fuse only, does not x x x x x x x x x x x x x
include fuse holder & cap - see HS1823)
HS1823 1821013 913089-00123 Fuse Holder and Cap x x x x x x
HS1824 1824011 00-134429 23"-Long Cut Off Rod x x x x x x x x x x x
HS1832 6108000 13332-00005 Red Rectangular Pilot Light (Fits Hobart HWS4 & HWS4C) x x x
HS1836 6108002 00-132654-00004 Round Red Pilot Light x x x x x x x x
HS1872 1872008 00-130445-00004 15-Amp Toggle Switch, 125V x x x x x x x x x x x
HS1879 1872009 Lighted On/Off Rocker Switch x x
HS1881 1881002 00-913089-00166 B200 Thermostat x x x x x x x x x x x x x
HS2145 2145023 00-444950 B200 Thermostat Knob x x x x x x x x x x x x x
HS2150-232 2150232 Hi-Lo Label with Hardware x x x x x x x x x x x x x
HS3005 3005004 00-130445-00040 Film Core Axle (5/8" x 21 15/16" Long) x x x x
HS3010 3010016 "D" Ring Film Retainer x
HS3047 3005047 Film Core Axle (5/8" x 24" Long) x x
HS5901 5901011 00-130585-00001 NonStick Cover 6" x 15" x x x x x
HS5902 5901014 NonStick Cover 6" 9" x x
x
HS5903 5901001 00-133320-00001 NonStick Cover 8" x 15" x x
HS5904 5901010 3345687 Nonstick Cover 6” x 14” (Fits Hobart HWS4 & HWS4C) TT-912 Hot Plate
HS5905 5901016 NonStick Cover 9" x 12"
HS6101 6101020 6"x15" Hot Plate Ass'y Kit, 110V (Inc. Thermostat, x x x x x x x x x
Element, Fabricated Plate, Wires & Non-Stick Cover)
HS6102 6102043 8" x 15" Hot Plate Ass'y Kit, 110V (Inc. Thermostat, x x
Element, Fabricated Plate, Wires & Non-Stick Cover)
HS6110 6110016 913089-00167 Heating Element Assembly ( for 6" x 15", 8" x 15") x x x x x x x x x x
HS6113 6110023 3" White Core Adapter/End Caps (Set of 2 w/ Bracket) x x x x x x x x
HS6114 6305018 Bearing Block Set (2004 on) x x x x x x
HS6140 6110040 Seal Plate Wire Harness Kit (3 Wires) x x x x
HS6301 6301047 Film Roller Assembly Kit (2 Roller Kit) x x x x
HS6305 6305041 00-046495 Seal Plate Wire Harness Kit (3 Wires) x x x x x x
HS6375 6305075 444617 Bearing Block Kit w/ Mounting Bracket (pre 2004) x x x x
HS6504 6504022 Heating Element 6" x 9" x x
CORD N/A 00-130445-001 Power Cord - 8' Black (UL Listed) x x x x x x x x x x x x x
* "Slo Blo" fuse means fuse will not burn out after a single shortout or power spike
