Page 180 - Alfa International 2023 Catalog

FOR HOLLYMATIC SUPER PATTY MAKER

HOL-MOTOR HOL177
(Set of all
Four)

HOL-M234,
HOL-M438

HOL227 HOL107

HOL-RING
HOL206

HOL695
HOL140 (All parts)
HOL412 HOL188

AlfA # Holly # Description
HOL002 2002 Bearing, Main Shaft (Right Hand)
HOL095 2095 Insert, Rear, Threaded (2 required, sold individually)
HOL102 2102 Bushing, Main Shaft
HOL107 2107 Hopper Bolt, Long - 2-3⁄8" head (2 required, sold individually)
HOL140 3140 T-Wrench, 1/2"
HOL177 N/A Hopper Bolt Kit (Set of 4)
HOL178 N/A Insert Kit
HOL188 2188 Lock pin, Nut, Washer
HOL206 2206 Taper Pin
HOL227 2227 Hopper Bolt Gear Guard, Short, 1-7⁄8" head,
(2 required, sold individually)
HOL395 2395 Insert, Front, Threaded (right hand)
HOL102
HOL412 2412 Plate, .062"
HOL595 2595 Insert, Front, Threaded (left hand)
HOL695 7695 Main Shaft & Drive Arm Ass'y (also includes parts HOL206,
HOL188 and HOL412)
HOL791 7791 Insert, "Special," Rear Locating
HOL-M234 2037 Mold Plate 2oz, F, 3/4
HOL-M438 2037 Mold Plate 4oz, M, 3/8
HOL-MOTOR N/A Motor 3/4-HP, 115/230V,60Hz, 1 Phase, 11.6A
HOL-RING N/A Aluminum ring for mounting HOL-MOTOR, 2 required
HOL002

The above parts are sold by Alfa International as replacement parts for Hollymatic Patty Makers. Alfa is not affiliated with Hollymatic.
