PARTS FOR HOBART MIXERS

Transmission Gear Unit – Models A120 and A200

HM2-615 SHAFT SERVICE KIT

The HM2-615 Shaft Service Kit, shown in
the schematic at left, includes the parts
HM2-710 shown below. These parts may also
be ordered separately.

HM2-636

HM2-052 HM2-710 HM2-636

HM2-745

HM2-651 HM2-052

HM2-748

HM2-304
HM2-745 HM2-651

HM2-513
HM2-304

HM2-748
HM2-128

HM2-615 HM2-128
(Entire
Assembly) HM2-513

fiTs MoDel seRies
alfa # HobaRT# DescRipTioN a 120 a 200
HM2-052 BB-005-02 Ball Bearing (not included in kit HM2-615, below) x x
HM2-651 124765-1 Spacer 3/4" - Worm wheel shaft (not included in x x
kit HM2-615, below)

alfa # HobaRT# DescRipTioN a 120 a 200
HM2-615 293615 Worm Wheel Shaft Service Kit, Includes All Parts x x
Listed Below (parts are also sold separately)*
HM2-128 291128 Worm Wheel Shaft x x
HM2-304 12430-4 Key x x
HM2-513 124751-3 Bronze Worm Wheel Gear and Bushing (60 HZ) x x
HM2-636 WS-006-36 Retaining Washer (Pkg./10) (1 in Kit) x x
HM2-710 12710 Retaining Nut x x
HM2-745 124745 Worm Wheel Shaft Washer
(Not included in HM2-615 Kit) x x
HM2-748 124748 Steel Gear (15T) x

*Note: HM2-615 Kit includes 1 ea. HM2-636 Retaining Washer. HM2-636 package of 10 available separately.
The above parts are sold by Alfa International as replacement parts for Hobart Mixers. Alfa is not affiliated with Hobart.
